Overview
OHAUS Guardian 5000™ Hotplates Stirrers are designed for safety and simplicity in all research, academic and industrial applications. The design ensures proper mixing and temperature control of the top plate or your sample when using the optional temperature probe. Heating models include a Single Point Calibration feature for multiple setpoints. Select from five models with three plate sizes for your everyday heating and stirring applications.
Applications
Boiling Water, Water/Oil Bath Preparation, Sample and Solution Preparation, Dissolving Buffers and Reagents, Preparing Media, Concentrating Samples
Display
Backlit LCD Display for temperature and speed, green indicator lights when unit is heating and stirring, prominent hot top indicator light, probe in use icon, Single Point Calibration icon
Operation
Stirring from 60 to 1600 rpm, Temperature range of ambient +5°C to 500°C (ceramic top) or 380°C (aluminum top), power cord (included), stirring models include a 1.5” (3.8 cm) PTFE coated stir bar
Communication
N/A
Construction
Probe connection, SmartHousing™ stays cool to the touch and is chemical resistant, IP21 Ingress Protection, polycarbonate front panel, control knobs, On/Off switch for heater disconnect, built-in support rod holder, easy to clean ceramic or aluminum tops
Design Features
Hot top indicator light, audible alarm, SafetyHeat™ protection shuts off the heater in the event of a malfunction, temperature calibration feature for 3 probe and 3 plate setpoints
Features
SafetyHeat™ protects the lab - an industry-leading early detection system uses two independent safety controls to monitor the electronics and stop heating before an overtemperature condition occurs.
Precise stirring from 60 to 1600 rpm is made possible by the design of a powerful motor, strong magnet and software controlled ramp rate, ensuring secure magnetic coupling for viscous applications.
The bright LCD display includes large temperature and speed settings, intuitive icons and a prominent hot top indicator – all designed to quickly and easily monitor performance from across the lab.
Documents
Models
Ohaus E-G51Hp07C
Auxiliary Display Model
Custom Back-lit LCD
Internal Calibration
Temperature Calibration 3 Plate/3 Probe
Control
Digital
In Use Cover
Available as an Accessory
Ohaus E-G51Hs07C
Auxiliary Display Model
Custom Back-lit LCD
Internal Calibration
Temperature Calibration 3 Plate/3 Probe
Control
Digital
In Use Cover
Available as an Accessory
Ohaus E-G51Hs10C
Auxiliary Display Model
Custom Back-lit LCD
Internal Calibration
Temperature Calibration 3 Plate/3 Probe
Control
Digital
In Use Cover
Available as an Accessory
Ohaus E-G51Hsrdm
Auxiliary Display Model
Custom Back-lit LCD
Internal Calibration
Temperature Calibration 3 Plate/3 Probe
Control
Digital
In Use Cover
Available as an Accessory
Ohaus E-G51St07C
Auxiliary Display Model
Custom Back-lit LCD
Internal Calibration
Temperature Calibration 3 Plate/3 Probe
Control
Digital
In Use Cover
Available as an Accessory
